2-3 Standard Model List
OMNUC G5-Series AC Servo Drives Users Manual (Built-in MECHATROLINK-II communications type)
2
Standard Models and External Dimensions
Reactors
Mounting Brackets (L-Brackets for Rack Mounting)
Servo Drive Reactor
Model
Number of
power
phases
Model
R88D-KNA5L-ML2
Single-phase
3G3AX-DL2002
R88D-KN01L-ML2 3G3AX-DL2004
R88D-KN02L-ML2 3G3AX-DL2007
R88D-KN04L-ML2 3G3AX-DL2015
R88D-KN01H-ML2
Single-phase 3G3AX-DL2002
3-phase 3G3AX-AL2025
R88D-KN02H-ML2
Single-phase 3G3AX-DL2004
3-phase 3G3AX-AL2025
R88D-KN04H-ML2
Single-phase 3G3AX-DL2007
3-phase 3G3AX-AL2025
R88D-KN08H-ML2
Single-phase 3G3AX-DL2015
3-phase 3G3AX-AL2025
R88D-KN10H-ML2
Single-phase 3G3AX-DL2015
3-phase 3G3AX-AL2025
R88D-KN15H-ML2
Single-phase 3G3AX-DL2022
3-phase 3G3AX-AL2025
R88D-KN20H-ML2
3-phase
3G3AX-AL2055
R88D-KN30H-ML2
R88D-KN50H-ML2 3G3AX-AL2110
R88D-KN06F-ML2
3G3AX-AL4025R88D-KN10F-ML2
R88D-KN15F-ML2
R88D-KN20F-ML2
3G3AX-AL4055
R88D-KN30F-ML2
R88D-KN50F-ML2 3G3AX-AL4110
Specifications Model
R88D-KNA5L-ML2/-KN01L-ML2/-KN01H-ML2/-KN02H-ML2 R88A-TK01K
R88D-KN02L-ML2/-KN04H-ML2 R88A-TK02K
R88D-KN04L-ML2/-KN08H-ML2 R88A-TK03K
R88D-KN10H-ML2/-KN15H-ML2/-KN06F-ML2/-KN10F-ML2/-KN15F-ML2 R88A-TK04K
