5-22
Set Values
Value Function Description
0 Fault output ON: Fault output (with protective function working)
1 Operation in progress ON: Operation in progress (with RUN command input or inverter
output)
2 Frequency detection ON: Frequency detection (with frequency reference coinciding with
output frequency)
3 Idling ON: Idling (at less than min. output frequency)
4 Frequency detection 1
ON: Output frequency y frequency detection level (n58)
5 Frequency detection 2
ON: Output frequency x frequency detection level (n58)
6 Overtorque being
monitored (NO-contact
output)
Output if any of the following parameter conditions is satisfied.
• Overtorque detection function selection (n59)
• Overtorque detection level (n60)
7 Overtorque being
monitored (NC-contact
output)
• Overtorque detection time (n61)
Note NO contact: ON with overtorque being detected; NC contact:
OFF with overtorque being detected
10 Alarm output ON: Alarm being detected (Nonfatal error being detected)
11 Base block in progress ON: Base block in progress (in operation with output shutoff)
12 RUN mode ON: Local mode (with the Digital Operator)
13 Inverter ready ON: Inverter ready to operate (with no fault detected)
14 Fault retry ON: Fault retry (Inverter resetting with fault retry (n48) not set to 0)
15 UV in progress ON: Undervoltage being monitored (main circuit undervoltage UV or
UV1 detected)
16 Rotating in reverse
direction
ON: Rotating in reverse direction
17 Speed search in progress ON: Speed search in progress
Note Use “operation in progress” (set value: 1) or “idling“ (set value: 3) setting for the timing for stopping
the motor using a brake. To specify a precise stop timing, set “frequency detection 1” (set value: 4)
or “frequency detection 2” (set value: 5), and set the frequency detection level (n58).
Basic Operation
Chapter 5
