Omron SYSDRIVE 3G3JV

1-2
1-1 Function
The compact simple SYSDRIVE 3G3JV-Series Inverter ensures greater ease of use
than any conventional model.
The 3G3JV Inverter meets EC Directives and UL/cUL standard requirements for world-
wide use.
H SYSDRIVE 3G3JV Inverter Models
• The following 3-phase and single-phase 200-V AC-class, and 3-phase 400-V AC-class 3G3JV mod-
els are available.
Rated voltage Protective structure Maximum applied
motor capacity
Model
3-phase 200 V AC Panel-mounting models
( f i IP20)
0.1 (0.1) kW 3G3JV-A2001
p
g
(conforming to IP20)
0.25 (0.2) kW 3G3JV-A2002
0.55 (0.4) kW 3G3JV-A2004
1.1 (0.75) kW 3G3JV-A2007
1.5 (1.5) kW 3G3JV-A2015
2.2 (2.2) kW 3G3JV-A2022
3.7 (3.7) kW 3G3JV-A2037
Single-phase 200 V AC Panel-mounting models
( f i IP20)
0.1 (0.1) kW 3G3JV-AB001
gp
g
(conforming to IP20)
0.25 (0.2) kW 3G3JV-AB002
0.55 (0.4) kW 3G3JV-AB004
1.1 (0.75) kW 3G3JV-AB007
1.5 (1.5) kW 3G3JV-AB015
3-phase 400 V AC Panel-mounting models
( f i IP20)
0.37 (0.2) kW 3G3JV-A4002
p
g
(conforming to IP20)
0.55 (0.4) kW 3G3JV-A4004
1.1 (0.75) kW 3G3JV-A4007
1.5 (1.5) kW 3G3JV-A4015
2.2 (2.2) kW 3G3JV-A4022
3.7 (3.7) kW 3G3JV-A4037
Note 1. The figures in parentheses indicate typical motor capacities in Japan.
Note 2. It is not possible to connect a Braking Resistor or Braking Unit to a 3G3JV-series Inverter.
Select an Inverter from another series if the application requires braking control.
H International Standards (EC Directives and UL/cUL Standards)
The 3G3JV Inverter meets the EC Directives and UL/cUL standard requirements for worldwide use.
Classification Applicable standard
EC Directives
EMC Directive EN50081-2 and EN5008-2
Low-voltage Directive prEN50178
UL/cUL UL508C
Overview Chapter 1
