9-1 Inverter Specifications
3-phase
200 V AC
Model 3G3JV- A2001 A2002 A2004 A2007 A2015 A2022 A2037
p
200-V AC
models
Power
supply
Rated voltage and
frequency
3-phase 200 to 230 V AC at 50/60 Hz
pp y
Allowable voltage
fluctuation
–15% to 10%
Allowable
frequency
fluctuation
±5%
Power supply capacity (kVA)
(See note 1.)
0.4 0.9 1.6 2.7 4.3 5.9 9.3
Heat radiation (W) 13.0 18.0 28.1 45.1 72.8 94.8 149.1
Weight (kg) 0.5 0.5 0.8 0.9 1.3 1.5 2.1
Cooling method Natural cooling Cooling fan
Single-
h
Model 3G3JV- AB001 AB002 AB004 AB007 AB015 --- ---
g
phase
200-V AC
models
Power
supply
Rated voltage and
frequency
Single-phase 200 to 240 V AC at 50/60 Hz
models
pp y
Allowable voltage
fluctuation
–15% to 10%
Allowable
frequency
fluctuation
±5%
Power supply capacity (kVA)
(See note 1.)
0.5 0.9 1.6 2.7 4.3 --- ---
Heat radiation (W)
(See note 2.)
14.1 20.0 31.9 51.4 82.8 --- ---
Weight (kg) 0.5 0.5 0.9 1.5 1.5 --- ---
Cooling method Natural cooling Cooling fan
Max. applicable motor capacity (kW) 0.1 0.2 0.4 0.75 1.5 2.2 3.7
Output
ifi
Rated output capacity (kVA) 0.3 0.6 1.1 1.9 3.0 4.2 6.7
p
specifi-
cations
Rated output current (A) 0.8 1.6 3.0 5.0 8.0 11.0 17.5
cat
i
ons
Rated output voltage (V) 3-phase 200 to 240 V AC (according to the input voltage)
Max. output frequency 400 Hz parameter setting
Control
charac-
Harmonic-current
countermeasures
DC reactor (option) connection possible
teristics
Control method Sine wave PWM (V/f control)
Carrier frequency 2.5 to 10.0 kHz (in vector control)
Frequency control range 0.1 to 400 Hz
Frequency precision
(temperature characteristics)
Digital commands: ±0.01% (–10°C to 50°C)
Analog commands: ±0.5% (25°C ± 10°C)
Frequency setting resolution Digital commands: 0.1 Hz (less than 100 Hz)
and 1 Hz (100 Hz or over)
Analog commands: 0.06 Hz/60 Hz (equivalent to 1/1000)
Output frequency resolution 0.01 Hz
