Omron SYSDRIVE 3G3JV

2-15
2-2-4 Wiring around the Main Circuit
H Wire Size, Terminal Screw, Screw Tightening Torque, and Molded-case
Circuit Breaker Capacities
• For the main circuit and ground, always use 600-V polyvinyl chloride (PVC) cables.
• If any cable is long and may cause voltage drops, increase the wire size according to the cable length.
D 3-phase 200-V AC Model
Model
3G3JV-
Terminal symbol Terminal
screw
Screw
tightening
torque
(NSm)
Wire size
(mm
2
)
Recomme
nded wire
size
(mm
2
)
Molded-c
ase
circuit
breaker
capacity
(A)
A2001
R/L1, S/L2, T/L3, –, +1, +2,
U/T1, V/T2, W/T3
M3.5 0.8 to 1.0 0.75 to 2 2 5
A2002
R/L1, S/L2, T/L3, –, +1, +2,
U/T1, V/T2, W/T3
M3.5 0.8 to 1.0 0.75 to 2 2 5
A2004
R/L1, S/L2, T/L3, –, +1, +2,
U/T1, V/T2, W/T3
M3.5 0.8 to 1.0 0.75 to 2 2 5
A2007
R/L1, S/L2, T/L3, –, +1, +2,
U/T1, V/T2, W/T3
M3.5 0.8 to 1.0 0.75 to 2 2 10
A2015
R/L1, S/L2, T/L3, –, +1, +2,
U/T1, V/T2, W/T3
M3.5 0.8 to 1.0 2 to 5.5 2 20
A2022
R/L1, S/L2, T/L3, –, +1, +2,
U/T1, V/T2, W/T3
M3.5 0.8 to 1.0 2 to 5.5 3.5 20
A2037
R/L1, S/L2, T/L3, –, +1, +2,
U/T1, V/T2, W/T3
M4 1.2 to 1.5 2 to 5.5 5.5 30
Design Chapter 2
