Omron SYSDRIVE 3G3JV

5-7
5-4 Selecting the Operation Command
The following description provides information on how to input operation commands to
start or stop the Inverter or change the direction of rotation of the Inverter.
Three types of command input methods are available. Select either one of them accord-
ing to the application.
H Selecting the Operation Mode (n02)
• Select the method of operation mode input to start or stop the Inverter.
• The following method is enabled in remote mode only. The command can be input through key se-
quences on the Digital Operator.
n02
Operation Command Selection Changes during
operation
No
Setting
range
0 to 2 Unit of
setting
1 Default setting 0
Set Values
Value Description
0 The RUN and STOP/RESET Keys of the Digital Operator are enabled.
1 Multi-function input in 2- or 3-wire sequence through the control circuit terminals is enabled.
2 Operation commands via RS-422/485 communications are enabled.
H Selecting the STOP/RESET Key Function (n06)
• When parameter n02 is set to 1, set whether or not to use the STOP/RESET Key of the Digital Opera-
tor to stop the Inverter in remote mode. The STOP/RESET Key is always enabled in local mode re-
gardless of the setting in n02.
n06
STOP Key Function Selection Changes during
operation
No
Setting
range
0, 1 Unit of
setting
1 Default setting 0
Set Values
Value Description
0 The STOP/RESET Key of the Digital Operator is enabled.
1 The STOP/RESET Key of the Digital Operator is disabled. This setting is available only when
the Digital Operator is selected for operation command input.
Basic Operation
Chapter 5
