7-10-5 Ladder Program
• Transfer the created protocol to the Communications Board.
• The following example describes how to control the Inverter with this protocol.
• Before using this program in your system, be sure to check the word and data memory allocations and
change them if necessary so that there will be no word or data memory duplication.
• This program will stop all communications if a communications error or fault occurs. Be sure to set n68
for communications time-over detection selection to 0 through 2 so that the system will stop with time-
over detection.
H Memory Allocations
D Starting Communications and Status Signals
Word Functions common to all Slaves
000000 Inverter control communications (continued when set to ON)
000001 Communications error output (on hold when a communications error or fault
occurs)
000002 Communications fault reset
D Inverter Control Input (Register 0001 RUN Command)
Word Slave 1 function Word Slave 2 function Word Slave 3 function
000100 RUN command 000200 RUN command 000300 RUN command
000101 Forward/Reverse 000201 Forward/Reverse 000301 Forward/Reverse
000102 External fault 000202 External fault 000302 External fault
000103 Fault reset 000203 Fault reset 000303 Fault reset
000104 Always set to 0. 000204 Always set to 0. 000304 Always set to 0.
000105 Multi-function input 1 000205 Multi-function input 1 000305 Multi-function input 1
000106 Multi-function input 2 000206 Multi-function input 2 000306 Multi-function input 2
000107 Multi-function input 3 000207 Multi-function input 3 000307 Multi-function input 3
000108 Multi-function input 4 000208 Multi-function input 4 000308 Multi-function input 4
000109 Always set to 0. 000209 Always set to 0. 000309 Always set to 0.
000110 Always set to 0. 000210 Always set to 0. 000310 Always set to 0.
000111 Always set to 0. 000211 Always set to 0. 000311 Always set to 0.
000112 Always set to 0. 000212 Always set to 0. 000312 Always set to 0.
000113 Always set to 0. 000213 Always set to 0. 000313 Always set to 0.
000114 Always set to 0. 000214 Always set to 0. 000314 Always set to 0.
000115 Always set to 0. 000215 Always set to 0. 000315 Always set to 0.
D Frequency Reference of Inverter (Register 0002 Frequency Reference)
DM Function
D00001 Slave 1 frequency reference
D00002 Slave 2 frequency reference
D00003 Slave 3 frequency reference
