Omron SYSDRIVE 3G3JV

5-10
n42
Frequency Reference Bias Changes during
operation
Yes
Setting
range
–99% to 99%
(Max. frequency = 100%)
Unit of
setting
1% Default setting 0
D Analog Frequency Reference Filter Time (n43)
• The digital filter with a first-order lag can be set for analog frequency references to be input.
• This setting is ideal if the analog input signal changes rapidly or the signal is subject to noise interfer-
ence.
• The larger the set value is, the slower the response speed will be.
n43
Analog Frequency Reference Filter Time Changes during
operation
No
Setting
range
0.00 to 2.00 (s) Unit of
setting
0.01 s Default setting 0.10
5-5-4 Setting Frequency References through Key Sequences
The following description provides information on parameters related to frequency ref-
erence settings through key sequences on the Digital Operator
H Setting Frequency References 1 through 8 and the Inching Frequency
Command (n21 through n28 and n29)
A total of nine frequency references (frequency references 1 through 8) and an inching frequency com-
mand can be set together in the Inverter.
D Setting Frequency References 1 through 8 (n21 through n28)
n21
Frequency Reference 1 Changes during
operation
Yes
Setting
range
0.0 to max. frequency Unit of
setting
0.01 Hz (see
note 1)
Default setting 6.0
n22
Frequency Reference 2 Changes during
operation
Yes
Setting
range
0.0 to max. frequency Unit of
setting
0.01 Hz (see
note 1)
Default setting 0.0
n23
Frequency Reference 3 Changes during
operation
Yes
Setting
range
0.0 to max. frequency Unit of
setting
0.01 Hz (see
note 1)
Default setting 0.0
n24
Frequency Reference 4 Changes during
operation
Yes
Setting
range
0.0 to max. frequency Unit of
setting
0.01 Hz (see
note 1)
Default setting 0.0
n25
Frequency Reference 5 Changes during
operation
Yes
Setting
range
0.0 to max. frequency Unit of
setting
0.01 Hz (see
note 1)
Default setting 0.0
Basic Operation
Chapter 5
