5-11
n26
Frequency Reference 6 Changes during
operation
Yes
Setting
range
0.0 to max. frequency Unit of
setting
0.01 Hz (see
note 1)
Default setting 0.0
n27
Frequency Reference 7 Changes during
operation
Yes
Setting
range
0.0 to max. frequency Unit of
setting
0.01 Hz (see
note 1)
Default setting 0.0
n28
Frequency Reference 8 Changes during
operation
Yes
Setting
range
0.0 to max. frequency Unit of
setting
0.01 Hz (see
note 1)
Default setting 0.0
Note 1. Values will be set in 0.1-Hz increments if the frequency is less than 100 Hz and 1-Hz incre-
ments if the frequency is 100 Hz or over.
Note 2. Frequency reference 1 is enabled with n03 for frequency reference selection set to 1.
Note 3. Frequency references 2 through 8 are enabled by setting multi-step speed references 1, 2,
and 3 in n36 through n39 for multi-function input. Refer to the following table for the relation-
ship between multi-step speed references 1 through 3 and frequency references 1 through 8.
Frequency reference Multi-step speed
reference 1
(Set value: 6)
Multi-step speed
reference 2
(Set value: 7)
Multi-step speed
reference 3
(Set value: 8)
Frequency reference 1 OFF OFF OFF
Frequency reference 2 ON OFF OFF
Frequency reference 3 OFF ON OFF
Frequency reference 4 ON ON OFF
Frequency reference 5 OFF OFF ON
Frequency reference 6 ON OFF ON
Frequency reference 7 OFF ON ON
Frequency reference 8 ON ON ON
No multi-step speed reference 3 settings will be required if only frequency references 1 through 4 are
used, for example. Any multi-step speed reference not set is regarded as turned-OFF input.
D Setting the Inching Frequency Command (n29)
• The inching frequency command must be set as multi-function input in order to use the inching fre-
quency command.
n29
Inching Frequency Command Changes during
operation
Yes
Setting
range
0.0 to max. frequency Unit of
setting
0.01 Hz (see
note 1)
Default setting 6.0
Note 1. The value will be set in 0.1-Hz increments if the frequency is less than 100 Hz and 1-Hz incre-
ments if the frequency is 100 Hz or over.
Basic Operation
Chapter 5
