7-32
H Manuals
• Refer to the following manuals for the peripheral devices and support software in detail.
Product Catalog No.
SYSMAC CS-series Programmable Controllers Operation Manual: W339
Programming Manual: W340
SYSMAC CJ-series Programmable Controllers Operation Manual: W393
Programming Manual: W394
SYSMAC C200HX/HG/HE Programmable Controllers Installation Manual: W302
Operation Manual: W303
SYSMAC CQM1H Programmable Controllers and Inner Boards Operation Manual: W363
Programming Manual: W364
CS1W-SCB21/41 Serial Communications Boards
CS1W-SCU21/41 Serial Communications Units
W336
C200HW-COM06-EV1 Communications Board W304
WS02-PSTC1-E CX-Protocol W344
WS01-PSTF1-E Protocol Support Tool W319
H Communications Boards
• Communications Boards are required for communications via the RS-422/485 port. The Communica-
tions Boards that can be used are listed below.
Note The RS-232C port can be used if an RS-422/485 conversion adapter is installed. For ease of wir-
ing, however, it is recommended that the RS-422/485 port be used. The following information is
for the RS-422/485 port.
Series Communications Board
model
Mounting method Specifications
SYSMAC CS Series CS1W-SCB41 As an inner board of
the CPU Unit
• One RS-232C port
• One RS-422/485 port
• Protocol macro func-
tion
SYSMAC CJ Series CJ1W-SCU41 As a CPU Bus Unit • One RS-232C port
• One RS-422/485 port
• Protocol macro func-
tion
SYSMAC
C200HX/HG/HE
C200HW-COM06-EV1
Note Make sure that the
model number has the
suffix “EV1,” otherwise
the CRC-16 check code
cannot be used.
Mounted to an optional
slot of the CPU Unit
• One RS-232C port
• One RS-422/485 port
• Protocol macro func-
tion
SYSMAC CQM1H CQM1H-SCB41
(Used on CQM1H-CPU51/61.)
As an inner board of
the CPU Unit
• One RS-232C port
• One RS-422/485 port
• Protocol macro func-
tion
Communications Chapter 7
