9-7
H Dedicated Accessories
Name Model Description
Digital Operator (with
adjuster)
3G3IV-PJVOP140 Operator used to perform operations for 3G3JV
and 3G3MV Inverters. It is identical to the Digital
Operator attached to standard 3G3MV Inverters,
and has a built-in EEPROM in which the
Inverter’s parameter settings can be stored. If the
Digital Operator Case (3G3IV-PEZZ08386A) is
used, the Inverter can be mounted in a control
panel, or operated by remote control.
Digital Operator (without
adjuster)
3G3IV-PJVOP146 Operator used to perform operations for 3G3JV
and 3G3MV Inverters by remote control. It has a
built-in EEPROM in which the Inverter’s
parameter settings can be stored.
Digital Operator Case (for
3G3IV-PJVOP140)
3G3IV-PEZZ08386A Case for 3G3IV-PJVOP140 Digital Operator.
Mounting a 3G3IV-PJVOP140 in the Case allows
the Inverter to mounted in a control panel, or
operated by remote control.
Digital Operator
Connection Cable
3G3IV-PCN126/326 Required when using a Digital Operator with
3G3JV Inverters. Cable length: 1 m, 3 m.
DC Reactor
3G3HV-PUZDABj
Suppresses harmonic current generated from the
Inverter and improves the power factor of the
Inverter.
DIN Track Mounting
Bracket
3G3IV-PEZZ08122j
An adapter making it possible to easily mount the
Inverter to DIN tracks.
H Recommendable Separate Accessories
Name Model Description
AC Reactor (Yaskawa
Electric)
3G3IV-PUZBABj
Suppresses harmonic current generated from the
Inverter and improves the power factor of the
Inverter. Connect the AC Reactor to the Inverter if
the capacity of the power supply is much larger
than that of the Inverter.
EMC-conforming Input
Noise Filter (Rasmi)
3G3IV-PRSj
A Noise Filter on the input side meeting the EC
Directive’s EMC requirements.
The top of the Noise Filter has mounting screw
holes with which the Inverter mounted to the Noise
Filter can be secured.
Simple Input Noise Filter
(Yaskawa Electric)
3G3EV-PLNFDj
Each of these Filters connected to the power input
side eliminates noise in the power line connected to
the Inverter and suppresses noise leaking from the
Inverter to the power line.
Output Noise Filter (Tokin)
3G3IV-PLFj
Connect this Filter to the output side of the Inverter
to suppress the noise generated by the Inverter
from being transmitted to the output line.
Specifications Chapter 9
