Omron ZX Series User Manual

Through-beam Sensor Heads: FUN Mode Functions Section 3-8
83
n Correcting Display Values to Match Actual Width: Two-point Scaling A
Display values can be corrected if there is a discrepancy between the actual
incident beam width and the value displayed on the Amplifier Unit. When
actual widths are known, they are input at two points to correct the range and
offset of display values (see following figure).
To change only the offset without changing the range of display
values,
refer to n Offsetting Display Values: One-point
Scaling A
.
Example: Two-point Scaling A
S
ensor Head Emitte
r
S
ensor Head Emitte
r
S
ensor Head Receive
r
S
ensor Head Receive
r
Sensing object 1
Despite the actual 2.0-mm incident
beam width, 2.2 mm is displayed.
Sensing object 2
In addition, despite the actual 4.0-mm
incident beam width, 3.6 mm is displayed.
: Scaling value inputs
2.0
2.5
3.0
3.5
4.0
2.0
2.5
3.0
3.5
4.0
2.0
2.5
3.0
3.5
4.0
2.20
2.55
2.90
3.25
3.60
2.20
2.55
2.90
3.25
3.60
Actual incident beam width Actual incident beam widthMeasured value = Display value
Display value
Measured value
There are discrepencies
between actual incident beam
width and display values.

Omron ZX Series Specifications

General

Power Supply Voltage	12 to 24 VDC ±10%
Protection Rating	IP67
Output Type	NPN or PNP
Protection Circuit	Reverse polarity protection, short-circuit protection
Operating Temperature	-25 to 55°C (-13 to 131°F)
