2.4 Control 200 – configuration feasibilities
Depending on the intended use the converter Control 200 is available in 5 different configurations. The
main features and connection feasibilities are listed in the following table:
Configurations: CONTROL 200 C210 C220 C211 C221 C222
Relais-outputs
3 3 5 5 5
0-10 mA, or 0/4-20 mA-outputs
2 2 4 4 4
Connection feasibilities sensors:
1 sensor PF12 (pH)
X X X
1 sensor CF60 (conductivity)
X X X
2 sensors PF12 + PF12 (pH)
X
2 sensors PF12 + CF60 (pH + conductivity)
X
2 sensors CF60 + CF60 (conductivity)
X
