C200 HARDWARE
Instruction Manual C200 Part1 A1.doc
optek Danulat GmbH • D-45356 Essen • Germany
page 6
2 Technical Data
2.1 General data:
Mechanical Data
Panel-mount versions: IP66/NEMA4X (front only)
Dimensions 96mm x 96mm x 162mm deep
(3.78 in. x 3.78 in. x 6.38 in. deep)
Weight 0.6kg (1.32 Ib)
Power supply
Voltage requirements: 85 to 265V AC 50/60 Hz
12 to 30V DC (optional)
Power consumption: <10VA
Insulation: Mains to earth (line to ground) 2 kV RMS
Environmental Data
Operating temperature limits: -20 to 65°C (-4 to 149°F)
Storage temperature limits: -25 to 75°C (-13 to 167°F)
Operating humidity limits: Up to 95%RH non condensing
Safety
General safety: EN 61010-1
Overvoltage Class II on inputs and outputs
Pollution category 2
EMC
Emissions and immunity: Meets requirements of:
EN 61326 Class A (for industrial environment)
Languages
Languages configurable: English, French, German, Italian, Spanish
Display
Type: Dual 5-digits, 7-segment backlit LCD
Information: 16-character, single line dot-matrix
Energy-saving function: Backlit LCD configurable as ON or Auto-Off after 60s
Logbook (C211, C221 and C222): Electronic record of major process events and calibration data
Real-time clock (C211, C221 and C222): Records time for logbook and auto-manual functions
Relay Outputs – On/Off
Number of relays: Three for C210 and C220 or five for C211, C221 and C222
Number of set points: Three for C210 and C220 or five for C211, C221 and C222
Set point adjustment: Fully configurable as normal or failsafe high/low, bandwidth
alarm (composite high/low) or diagnostic alert
Hysteresis of reading: Programmable 0 to 5% in 0,1% increments
Delay: Programmable 0 to 60s in 1s intervals
Relay contacts: Single-pole changeover, Rating 5A, 115/230 V AC, 5A DC
Insulation: 2kV RMS contacts to earth/ground
Minimum load: voltage: 12V; current: 100 mA
Analog Outputs
Number of current outputs (fully isolated): Two for C210 and C220 or four for C211, C221 and C222
Output current: 0 to 10mA, 0 to 20mA or 4 to 20mA
Analog output programmable to any value between
0 and 22mA to indicate system failure
