Optek CONTROL 200 - Dual Input Redox (ORP)

C200 SOFTWARE
Instruction Manual C200 Part2 A1.doc
optek Danulat GmbH • D-45356 Essen • Germany
page 13
2.1.2.4 Dual Input Redox (ORP)
Measured Millivolts
Sensor A.
Sensor B.
Note. If Probe Type for both Sensor A and Sensor B is set to ORP (see Section
5.1.3), the lower display line shows Dual ORP.
Sample Temperature
Sensor A.
Sensor B.
Note. The measured temperature is displayed only if Temp. Sensor is not set to
None – see Section 5.1.3
Sensor A Offset
Displays the offset value for Sensor A set in A: Adjust Offset – see Section 4.1.3.
Sensor B Offset
Displays the offset value for Sensor B set in B: Adjust Offset – see Section 4.1.3.
Alarm 3 set to Wash (A3: Type, Section 5) – see Section 2.1.2.6
Alarm 3 not set to Wash.
Dual Redox
404
mV
-256
Temperature
25.6
Deg.C
24.4
Deg.C
mV
A: mV Offset
0
mV
B: mV Offset
0
mV
Wash Function
Dual Redox
