Optek CONTROL 200 - Back Panel CONTROL

C200 HARDWARE
Instruction Manual C200 Part1 A1.doc
optek Danulat GmbH • D-45356 Essen • Germany
page 12
3.2 Back panel CONTROL 200
Te rmina l B lo c k C
(Option Board)
Terminal Block B
Te rm i na l B lo c k A
Case Earth (Ground) Stud
LLine
N Neutral
E Connect supply earth (ground) to stud on case
A4 C
A5 NC Relay 1
A6 NO
A7 C
A8 NC Relay 2
A9 NO
A10 C
A11 NC Relay 3 (see Note below)
A12 NO
A13 +
Analog Output 1
A14 —
A15 +
Analog Output 2
A16 —
Term inal Block BTerminal block A
Temperature Compensator
Connections
Common
Third Lead
TC
B1
B2
B3
B4
B5
B6
B7
B8
B9
B10
B11
B12
B13
B14
B15
B16
Common
Third Lead
TC
Temperature Compensator
Connections
Te rm inal B lock C
(Option Board)
C1 Not Used
C2 Not Used
C3
C4
C5
C6 Not Used
C7 C
C8 NC Relay 4
C9 NO
C10 C
C11 NC Relay 5
C12 NO
C13 +
Analog Output 3
C14 —
C15 +
Analog Output 4
C16 —
Earth (Ground)
Stud on Case
Used for optional
RS485 connections –
refer to IM/PROBUS
85 to 265 V AC + 12
or to
Power
24 V AC – 24V DC
Supplies
Sensor A
Sensor B
