Screen flickers. Battery is insufficiently
charged
Charge battery
Use battery charger to run
the system.
Incorrect PAR reading with
optional PAR cuvette
attached
PAR sensor not connected Secure the connection
Incorrect temperature
reading with optional PAR
cuvette attached
Temperature sensor not
connected
Secure the connection
Charge Status Light
It only turns on when the
OS1p is turned off and the
unit is plugged in.
Green -
Yellow -
Red -
Flashing -
The light turns green when
the Nickel Metal Hydride
battery is fully charged.
It is yellow momentarily
when it is partially
charged.
It will be red when it is not
fully charged.
If the light is flashing,
check the charger
connection.
Nothing is required
Nothing is required
Turn on the OS1p and go
to diagnostics. Check
battery capacity for the
battery charging level. If it
is low you may want to
charge the system before
use.
Check the connection and
the wall outlet for proper
function.
!! Battery Low !!
Battery needs charging or the
system must be used with the
power cord
Charge the fluorometer or use a
power cord.
!!IR to High!!
Far red light too high Adjust it lower
“Fluorescent signal too
low”
The modulated light intensity is
too low
Adjust the modulated light
intensity or set the intensity with
Auto Gain
“FL > 3600 pos Det pin out” The modulated light source
intensity is too high
Adjust the modulated light
source gain downward, and the
intensity, or use Auto Gain.
