Table 3–11 Module 1, Right Magazine: Filled, Data Tapes in All Slots
Right Column 5 Column 4 Column 3 Column 2 Column 1
Row 1
8V1258L6 8V1255L6 8V1253L6 8V1250L6 8V1247L6
Row 2
8V1259L6 8V1256L6 8V1254L6 8V1251L6 8V1248L6
Row 3
8V1260L6 8V1257L6 8V1255L6 8V1252L6 8V1249L6
Loading the Magazines
Loading Media and Running Self Checks 3-15
16. When ready, reinstall the right magazine. Grasp the handle on the front of the
magazine with one hand while supporting the magazine's weight with the other.
Be careful to hold the magazine so that tapes do not fall out of the slots.
17. Carefully align the right magazine with the right magazine bay of the base
module, and gently push the magazine into the magazine bay until it latches into
place with a noticeable click.
18. Now load the magazines into the expansion modules.
Load the Magazines in the Expansion Modules
For each expansion module, proceed as follows:
1. Grip the front handle of the left magazine with one hand and slide the magazine
smoothly out of the enclosure like a long, narrow drawer, supporting the
underside with your other hand.
Each magazine contains 15 cartridge slots in thr
ee rows of five. The open ends of
the slots face the inside of the library, so that openings of left and right magazines
face each other when installed.
2. Place the left magazine upright on your work surface, with the handle facing left
and the slot openings facing you.
3. Load the magazine. Insert each cartridge into a magazine slot with the cartridge
hub down and the label and write-protect switch visible on the open side of the
magazine. Push the cartridge into the slot until the plastic retention spring snaps
into place.
The table below shows the left magazine loaded
with data cartridges:
Table 3–12 Module 2, Left Magazine: Filled, Data Tapes in All Slots
Left Column 1 Column 2 Column 3 Column 4 Column 5
Row 1
8V3247L6 8V3250L6 8V3253L6 8V3255L6 8V3258L6
Row 2
8V3248L6 8V3251L6 8V3254L6 8V3256L6 8V3259L6
Row 3
8V3249L6 8V3252L6 8V3255L6 8V3257L6 8V3260L6
4. When ready, reinstall the left magazine. Grasp the handle on the front of the
magazine with one hand while supporting the magazine's weight with the other.
Be careful to hold the magazine so that tapes do not fall out of the slots.
5. Carefully align the left magazine with the left magazine bay of the expansion
module, and gently push the magazine into the magazine bay until it latches into
place with a noticeable click.
6. Grip the front handle of the right magazine with one hand and slide the magazine
smoothly out of the enclosure, supporting the underside with your other hand.
