Oracle ZFS Storage Appliance Service Manual

Disk Shelf Hardware Overview
Shelf Device Types Data Slots Cache/Log Slots Notes/
Examples
(filler), Slot 23
(filler)
20 Data and 1-4
Cache devices
0 - 19 20 - 23 Software version
OS8.6.0 (or later)
is required for read
cache devices.
Up to four read
cache devices
installed in
consecutive slots.
Example slot
configuration:
Slot 20 (Cache), Slot
21 (Cache), Slot
22 (filler), Slot 23
(filler)
20 Data and 1-4 Log
or Cache devices
0 - 19 20 - 23 Software version
OS8.6.0 (or later)
is required for read
cache devices.
Up to four log
and read cache
devices installed
in consecutive
slots. Example slot
configuration:
Slot 20 (Log), Slot
21 (Cache), Slot
22 (Log), Slot 23
(Cache)
DE2-24C Data 0 - 23 none Fully populated
HDD data devices.
20 Data and 1-4 Log
devices
0 - 19 20 - 23 Twenty HDD
data devices and
up to four log
devices installed
in consecutive
slots. Example slot
configurations:
Slot 20 (Log), Slot
21 (Log), Slot 22
(Log), Slot 23 (Log)
Slot 20 (Log), Slot
21 (Log), Slot 22
Servicing the Disk Shelves 287

Oracle ZFS Storage Appliance Specifications

General

Connectivity	10GbE, 40GbE, InfiniBand, Fibre Channel
Protocols	NFS, SMB, iSCSI, Fibre Channel, HTTP
Operating System	Oracle Solaris
Data Protection	snapshots, clones, remote replication
Data Reduction	Inline compression, deduplication
High Availability	Redundant hardware components (controllers, power supplies, fans). Automatic failover between controllers. Hot-swappable drives and components. Cluster configurations for increased availability and scalability.
Management Interface	Web-based GUI, CLI, REST API
Storage Type	Hybrid (SSD + HDD), All-Flash
Storage Capacity	Up to several petabytes
Encryption	AES-256 encryption at rest
