Oracle ZFS Storage Appliance Service Manual

Replacing a ZS4-4 Fan Module
Fan modules cool the motherboard and its components. The fan modules are arranged in
stacked pairs (a front row and a back row) to provide redundancy. If you remove a failed fan
module, replace it immediately. Fan modules are hot-swappable and can be removed and
installed while the storage controller is running without affecting other hardware capabilities.
Use the following procedure to replace a ZS4-4 fan module.
1.
To flash the locator LED on the chassis to service, go to Maintenance >
Hardware in the BUI and click the associated locator icon , or go to the
service processor (SP) prompt and enter set /SYS/LOCATE status=on
2.
To locate the faulted component, go to Maintenance > Hardware > Fan and click
the row with an amber indicator.
The component is highlighted in the diagram.
3.
At the back of the controller, verify that cables have sufficient length and
clearance to extend the controller from the rack.
4.
Extend the controller from the rack as described in “Extending the Storage
Controller from the Rack” on page 51.
5.
Remove the top cover as described in “Removing the Top Cover” on page 52.
6.
Lift the green handle at the top of the fan module to unlock the fan module, and
pull the fan module straight up and out.
Caution - Excessive movement or rocking of the fan module during removal can cause damage
to the internal connector on the fan module board. When removing a fan module, do not rock it
back and forth.
7.
Position the replacement fan module so the connector on the bottom of the
module is aligned with the connector on the inside of the slot and all keying and
Servicing the ZS4-4 Controller 59

Oracle ZFS Storage Appliance Specifications

General

Connectivity	10GbE, 40GbE, InfiniBand, Fibre Channel
Protocols	NFS, SMB, iSCSI, Fibre Channel, HTTP
Operating System	Oracle Solaris
Data Protection	snapshots, clones, remote replication
Data Reduction	Inline compression, deduplication
High Availability	Redundant hardware components (controllers, power supplies, fans). Automatic failover between controllers. Hot-swappable drives and components. Cluster configurations for increased availability and scalability.
Management Interface	Web-based GUI, CLI, REST API
Storage Type	Hybrid (SSD + HDD), All-Flash
Storage Capacity	Up to several petabytes
Encryption	AES-256 encryption at rest
