13. PARTS LIST
xPlease contact your dealer to order parts. (See the back cover for telephone and fax numbers,
and mailing addresses.)
Symbol Part No. Description Specifications Q’ty Remarks
NF 4614-104 Circuit protector 119-0637(480V 75A) 1
LF 4519-037 Line filter FS5681-50-99 1
PL1 4600-341 Pilot lamp
NPA10
|
2H
|
WS
1
DR1 4531-717 Diode module DFA150AA160 1
DR2 – 7 4531-308 High speed diode module DBA200UA60 6
DR8 4531-505 Diode S2L60 1
TR1-4 4534-528 IGBT module CM200DY-12NF 4
TR5 4534-529 IGBT module SKM300GAL128D 1
SCR1 4530-412 Thyristor SG25AA20 1
CT1 4810-030 Current transformer TMH0.025X5X25X35 1
CT2 4406-009 Hole current detector HA400S3EH 1
T1 P10264B00 Inverter transformer P10264B00 1
T2 4810-351 Auxiliary transformer W-W02921A 1
L1 P10352B00 DC reactor P10352B00 1
L2,3,6,7,8 4739-497 Ferrite core E04RA400270150 5
L4 P10322L00 Input reactor P10322L00 1
L5 P10352C00A Choke coil P10352C00A 1
L11,12 4739-543 Ferrite core E04RA310190100 2
THP1 4258-041 Thermostat
US-602AXTTL 110
1
THP2 4614-057 Thermostat 67L080 1
THP3 4258-033 Thermostat 67L070 1
FM1,2 4805-074 Fan 4715SL-05W-B60-D00 2
SH 4403-116 Meter shunt KY400A 400A/60mV 1
TM1 4739-505 Terminal block TB10-01 12P 1
TM2 4739-504 Terminal block TB10-01 6P 1
R1 - 4 4516-119 Surge absorber
ENC911D
|
14A
4
R6 4509-819 Cement resistor 40SH 200ȍJ 1
R8
|
13,17
4509-704 Carbon resistor RD1/4W 1kȍJ 7
R14,15 4509-121 Metal film resistor
RNP
|
50SC
10ȍF
2
R16 4509-916 Cement resistor T20SH 2.2ȍJA 1
R18 4509-107 Carbon resistor RS2W
15ȍJ 1
R19,20,21 4509-128 Metal oxide film resistor RS2B 200kȍJ 3
R23,24 4501-039 Variable resistor
RV24YN20SB 5k
¶
2
R25,26 4509-883 Cement resistor 20SH 20kȍJ 2
R27a
|
d
4504-321 Non-inductive resistor NCRF22V 10ȍ 4
R28 4504-322 Non-inductive resistor NCRF22V 20ȍ 1
R29,R30 4509-704 Carbon resistor RD1/4W 1kȍJ 2
R31,R32 4509-922 Cement resistor 20SH 10ȍJA 2
C2 4518-530 Film capacitor US16X154JAASA 1
C4,C5 4518-519 Film capacitor MIC-ST3D182J 2
C7,C12 4518-402 Film capacitor 0.47µF
50V 2
C8,C9 4511-344
Aluminum electrode capacitor
400LGSN3300MBD13 2
C10 4518-533 Film capacitor US20X473JAASA 1
