No. P10355
 |73 |
13. PARTS LIST (continued)
Symbol Part No. Description Specifications Q’ty Remarks
C11 4518-528 Film capacitor US20X103JAASA 1
C13 4517-455 Ceramic capacitor 0.01µF 2kV 1
C14 4511-510
Aluminum electrode capacitor
LWA2N601MSMAZO 1
CON1 4730-421 Metal receptacle HS25R-10 1
CON2 4730-426 Metal receptacle 25-6BK 1
PCB1 P10352U00 Printed circuit board P10352U00 1
PCB2* P10264P00 Printed circuit board P10264P00 1
Refer to “NOTE” below.
PCB3 P10263Q00 Printed circuit board P10263Q00 1
PCB4 P10264V00 Printed circuit board P10264V00 1
PCB5 P10264T00 Printed circuit board P10264T00 1
PCB6 P10352M00 Printed circuit board P10352M00 1
PCB7 P10261Q00 Printed circuit board P10261Q00 1
PCB8 P10263R00 Printed circuit board P10263R00 1
PCB9 P10264R00 Printed circuit board P10264R00 1
PCB10 P10264X00 Printed circuit board P10264X00 1
PCB11 P10322X00 Printed circuit board P10322X00 1
PCB12 P10264S00 Printed circuit board P10264S00 1
@
4739-474 Grommet with film W-W02805 2
A
4735-038 Knob K-100 22RSB 1
B
4735-039 Cap K-100 22CSBL 1
Adjusting knob
C
4739-475 Rubber foot C-30-RK-3220 4
D
P10355W02 Control panel sheet P10355W02 1
E
4739-476 Cap W-W02814 2
F
P5801G03 Carrying Handle P5801G03 2
G
P10263G12 Bush P10263G12 4
H
P10264J01 Front cover P10264J01 1
I
P10263J02 Control panel cover P10263J02 1
J
4734-007 Machine socket DIX BE 50/70 2 Output terminal
Plug for
J
4734-025 Power cable connector DIX SKK 70 1 For 60mm
2
cable
Plug for
J
4734-026 Power cable connector DIX SKK 95 1 For 80 mm
2
cable
*NOTE: When ordering a printed circuit board P10264P00, provide the software
version on a label below a nameplate attached to the rear side of the welding power
source.
P10355 Ver. ###.###
.000
Replace the ###.### with software version.
Parts list for analog remote control (optional accessories)
Symbol Part no. Description Specifications Q’ty Remarks
R23,24 4501-039 Variable resistor RV24YN20SB 5Kȍ 2
PB 4250-077 Push button switch A2A-4R 1
4730-009 Metal socket plug DPC25-6A 1
4735-007 Knob
K-2195
i
large
j
2
K5416H02 350/500A scale plate K5416H02 1
