Panasonic AJ-SD93P/E - Avio Board [Aj-Ya93] (F4)

ELE-6
4. AVIO BOARD [AJ-YA93] (F4)
Note:
1. In order to perform the audio and video adjustments, Optional Board AJ-YA93 should be installed in the
AJ-SD93.
<1> Location of TPVR/SW
<2> Connection for Video Adjustment
VR300 VR302 TP421
TP420 TP422
VR4601
VR4203
VR202
VR4600
VR4501
VR201
VR200
VR4500
VR4202 VR4201 VR4200 SW4100 SW4001
HIGH
↕
600
HIGH
↕
600
AJ-SD93
W/AJ-YA93/YA94G
REF IN
SDI IN SDI OUT
GENLOCK
THRU OUT
MONITOR
TV
SIGNAL
GENERATOR
REF OUT
CF OUT
VIDEO MON OUT
VIDEO 1
VIDEO 2
VIDEO 3
CH B1
CH B2
CH B3
CH A
EXT REF
SIGNAL
GENERATOR
COMPOSITE
OUT
CABLE <1>
CABLE <2>
CABLE <3>
CABLE <4>
Note : Cables <1> - <4> should be same length.
