Panasonic AJ-SD93P/E - LISTA Connection and Boot up

MECH-22
3-30. LISTA Connection and Boot Up
R/P-L TP6701 RF/CUE
R/P-R TP6801 RF/CUE
ATF ERROR
PB-L TP6701 RF/CUE
R/P-L TP233 SERVO (F1)
R/P-R TP235 SERVO (F1)
TEST
POINT
TRIGGER (H SW)
PB-L TP232 SERVO (F1)
M. EQ.
PC (Personal Computer) (A/D board should be installed)
TAPE
NTSC : VFM3581KM or VFM3581KL (LISTA), VFM3000EDS (DV LISTA)
(PAL :
VFM3681KM or VFM3681KL (LISTA), VFM3000EDS (DV LISTA)
)
TOOL
VFK1481K (LISTA Software), VFK1186 (LISTA Cable), VFK1300 (AD Converter board)
<Classified list for LISTA Connection>
1. Connect the LISTA cable to A/D Board in the PC.
2. Connect the clips of the LISTA cable to test point on the P.C.Board.
3. Boot up the LISTA software on DOS mode.
4. After the LISTA software boot up, <<< FORMAT SELECT >>> display appears. Select the “DVCPRO 50” so
that the <<VTR SELECT>> Menu appears.
5. Select “AJ-D950” in <<VTR SELECT>> menu so that the <<Alignment Tape Select>> Menu appears.
♦ How to install and boot Up ♦
Make a directory like C : Lista and Copy all files in the floppy disk (VFK1481K : LISTA Software) to it on PC.
Type “LISTA” and press ENTER key, then the LISTA software VFK1481K boot up.
