Panasonic AJ-SD93P/E - Microcomputer (FLASH); PLD Chart; Software Version Upgrade Method

INF-20
12. SOFTWARE VERSION UPGRADE METHOD
12-1. Microcomputer (FLASH) / PLD Chart
Name of
Circuit
Board
Name
IC
Manufa-
cture
Ref. No.
Version up
Connector
Version up
Soft. & Tool
No. of
Program
Software
Paragraph
of
Procedures
CPLD ALTERA IP250 P250
VSI4319 12-2-5
F1 :
SERVO
Microcomputer
FLASH
Panasonic IP150 P151 VSI4318 12-2-3
F2 :
AVMON
AVMON FPG ALTERA IC3200 VSI4323 12-2-4
Microprocessor
FLASH (NTSC)
FLASH (PAL)
Panasonic IC1603
VSI4320
VSI4328
12-2-2
AVPROC FPG ALTERA IC I201, 901 VSI4321 12-2-4
DVPROC FPG ALTERA IC1501 VSI4322 12-2-4
F3 :
DPROC
D-I/F FPG ALTERA IC10501 VSI4324 12-2-4
F4 : AVIO AVIO FPG ALTERA IC3400 VSI4326 12-2-4
F5 : SDI SDI FPG ALTERA IC255
P1802
On the
DPROC
Board
1. Flash
Memory
Version-up
Tool
(VFK1304A)
2. Version-up
Software
(VFK1248N)
3. CPLD
Writer
(VFK1590)
4. CPLD
Version-up
Software
(Max Plus II
supplied from
ALTERA)
VSI4327 12-2-4
Table 12-1A-1
Figure 12-1A-2
F1: SERVO Board
IP400
(COMPONENT SIDE)
F2: AVMON Board
(COMPONENT SIDE)
F3 (SUB): 1394 MODULE Board
(COMPONENT SIDE)
IP16
(COMPONENT SIDE)
IP18
F3: DPROC Board
IP150
IC1603
IC3200
IP250
IC10501
IC1201
IC1501
P151
P250
P1802
IC901
