2-11. VFM3110EDS / EDL (PAL) (DV adjustment tape)
VIDEO PCM AUDIO
CUE TIME
(min.)
Signal Purpose
Signal
Purpose Signal
Purpose
0:00 Color bar EQ adjustment 1,102.5KHz ----- -----
3.
LIST OF RECOMMENDED MEASURING INSTRUMENTS
MODEL NO. (Example) NAME REMARK
TSG130A (NTSC) *1(opt.05)
NTSC analog composite & component signal generator
(with CF OUT)
TSG131A (PAL)
PAL analog composite & component signal generator
(with CF OUT)
SCH meter (NTSC)
Waveform monitor (NTSC)
1760 (op. SC) or 1780R
Vector scope (NTSC)
SCH meter (PAL)
Waveform monitor (PAL)
1761 (op. SC) or 1781R
Vector scope (PAL)
Tektronix
Oscilloscope
Digital voltmeter (D.V.M.)
Frequency counter
Audio noise meter
Audio analyzer
Spectrum analyzer
*1 : This option 05 is added for dvcpro service test signal. It include CF OUT Signal.
Please contact Tektronix if more detailed information is required.
