Panasonic AJ-SD93P/E - Tape Path Adjustment Procedure

MECH-9
3-10. Tape Path Adjustment Procedure
3-22. PLAY Tape Path
Limit Conf.
3-23. Conf. of ENV on
REV/REW FF mode
3-24. Conf. of PLAY Start ENV
3-25. REV Tape Path Conf.
3-26. FF/REW Tape Path Conf.
3-27. Screw Lock Tight of
A/C Head,T3,T4 Post
3-28. Conf. of Tape Damage for
Long Tape Play
END
START
3-11. Envelope Waveform Adj.
3-12. Post Limit Confirmation (PLAY)
3-14. A/C Head Tilt Adjustment
3-15. A/C Head Height Adjustment
3-16. A/C Head Tilt Confirmation
3-17. A/C Head Hei
g
ht Conf.
3-18. A/C Head
Azimuth & X-value Adj.
3-20. REV Tape Path Conf.
(T4 Post Adj.)
3-21. CTL Self-Recording
Level Conf.
T4 Post
Adj.
Each Post Limit
Conf.
Each Post Limit Conf.
and A/C Head Adj.
S4 Post Conf.
To PG and LISTA Adj.
OK
OK
OK
OK
OK
OK
OK
OK
NG
NG
NG
NG
NG
OK
NG
OK
NG
OK
NG
OK
NG
OK
NG
OK
OK
Each Post Limit
Conf.
3-19. Compensation
Adjustment of X Value
NG
OK
