Panasonic AJ-SD93P/E - Page 171

REF.No4000 SERIES
REF.No3000 SERIES
VR4002 VR4001
VR3100
VC3300
TP3300
TG3301
TG3220
AVMON P.C.BOARD (VEP83646) [F2]
CBA-1
(COMPONENT SIDE)
4
3
2
1
A B C D E F
FOIL SIDE COMPONENT SIDE
REF LOC
IC3305 A1
Q4001 F2
Q4002 E2
QR4001 E2
QR4002 E2
QR4003 F2
QR4004 E2
REF LOC REF LOC
IC3100 D2 P3001 C4
IC3101 C2
IC3102 D3 Q3100 D2
IC3103 D2 Q3101 D2
IC3104 D2 Q3102 D2
IC3105 B3 Q3103 D2
IC3200 B2 Q3300 C1
IC3201 A3 Q4200 D3
IC3300 C3 Q4201 D3
IC3301 D1 Q4202 E2
IC3302 B1 Q4203 E3
IC3303 D1 Q4204 E3
IC3304 B1 Q4205 F3
IC3306 C1 Q4206 E3
IC3307 C1 QR4200 E3
IC3400 B2
IC3401 D3
TG3301 B1
TG3220 A4
IC3402 D3
TP3300 B1
IC3403 C3
IC3404 C3
VC3300 C1IC3405 D3
VR3100 D2
IC4001 E1
VR4001 F2
IC4002 F1
VR4002 E2
IC4003 E1
IC4004 E2
IC4005 E2
IC4006 F1
IC4007 E1
IC4008 F2
IC4009 E2
IC4200 F3
IC4201 E3
IC4203 E3
IC4204 E3
