Panasonic AJ-SD93P/E - Page 27

INF-14
DVCPRO50/DVCPRO25
ATF HEAD TCG SW CH 1 CH 2 CH 3 CH 4
INT REGEN PBL1 VIDEO PBL2 VIDEO PBR1 VIDEO PBR2 VIDEO
PB
INT PRESET PBL1 AUDIO PBL2 AUDIO PBR1 AUDIO PBR2 AUDIO
INT REGEN RPL1 VIDEO RPL2 VIDEO RPR1 VIDEO RPR2 VIDEO
RP
INT PRESET RPL1 AUDIO RPL2 AUDIO RPR1 AUDIO RPR2 AUDIO
DV
ATF HEAD TCG SW CH 1 CH 2 CH 3 CH 4
INT REGEN RPL1 VIDEO RPL2 VIDEO RPR1 VIDEO RPR2 VIDEO
RP
INT PRESET RPL1 AUDIO RPL2 AUDIO RPR1 AUDIO RPR2 AUDIO
TCG SW
INT REGEN VIDEO Error rate is displayed
INT PRESET AUDIO Error rate is displayed
Specification of Error Rate
VTR mode Specification of Error Rate
DVCPRO
(All Modes)
DVCPRO (PB Head) alignment tape
playback
Under the “A” position at level meter
DV
(Rec/PB Modes)
DV (RP Head) Alignment tape
playback
Under the “A” position at level meter
