INF-36
B00: RF ADJUST
RF ADJUST sub-screen
Item
No.
SUPER
DISP.
Item contents
P00 DVCPRO 50M ADJUST
Adjustment for DVCPRO50 (50 Mbps)
Q00 DVCPRO 25M ADJUST
Adjustment for DVCPRO (25 Mbps)
R00 DV ADJUST
Adjustment for DV
DVCRRO 50M ADJUST sub-screen
Item
No.
SUPER
DISP.
Item contents
P-1 REC ADJUST
Adjustment of the recording system for DVCPRO50 (50 Mbps)
P-2 PB ADJUST
Adjustment of the playback system (PB head) for DVCPRO50 (50 Mbps)
P-3 RP ADJUST
Adjustment of the playback system (RP head) for DVCPRO50 (50 Mbps)
P-4 DEFAULT
LOAD/SAVE of the factory default adjustment values/initial values LOAD operation
• Perform operation in regard to the adjustment values for DVCPRO50 (50 Mbps).
Operation:
1. Move the cursor to P-4: DEFAULT and press “JOY STICK”.
2. Turn (↕) the ”JOY STICK” and move the cursor to the desired operation item.
SAVE ... Save the present set values as the factory default values.
LOAD ... Load the saved factory default values as the present set values.
(When SAVE operation has not been performed, the initial values
will be loaded.)
INIT LOAD ... Load the initial value (which designer decide) as the
present set values.
3. When the “JOY STICK” is pressed, the selected operation will be performed and it
will return to the item setting screen.
When the “MENU” button is pressed, no operation will be performed and it will
return the item setting screen.
DVCRRO 25M ADJUST sub-screen
Item
No.
SUPER
DISP.
Item contents
Q-1 REC ADJUST
Adjustment of the recording system for DVCPRO (25 Mbps)
Q-2 PB ADJUST
Adjustment of the playback system (PB head) for DVCPRO (25 Mbps)
Q-3 RP ADJUST
Adjustment of the playback system (RP head) for DVCPRO (25 Mbps)
Q-4 DEFAULT
LOAD/SAVE of the factory default adjustment values/initial values LOAD operation
• Perform operation in regard to the adjustment values for DVCPRO (25 Mbps).
Operation:
1. Move the cursor to Q-4: DEFAULT and press “JOY STICK”.
2. Turn (↕) the ”JOY STICK” and move the cursor to the desired operation item.
SAVE ... Save the present set values as the factory default values.
LOAD ... Load the saved factory default values as the present set values.
(When SAVE operation has not been performed, the initial values
will be loaded.)
INIT LOAD ... Load the initial value (which designer decide) as the
present set values.
3. When the “JOY STICK” is pressed, the selected operation will be performed and it
will return to the item setting screen.
When the “MENU” button is pressed, no operation will be performed and it will
return the item setting screen.
