Preparations before changing settings
Preparation
Operations on this unit
Buttons and boxes (continued)
Text boxes
These are used when you need to edit some text.
Display example Explanation
The touchscreen keyboard appears when you touch the text box.
Use the touchscreen keyboard to enter the text.
Refer to “Number and letter input” (P.188) for instructions on how to enter text.
Dialogues
These are elements that appear on the screen and are mainly used for settings.
They close automatically once you have registered the settings.
Touch
to close the dialogue without changing the setting.
(There may also be cases where you touch
at the top right of the screen to register the setting)
17
Preparations before changing settings
Preparation
Operations on this unit
How to read the screens
There are some items and icons common to the operations and settings screens.
The follow explains the items and icons.
A B C D
F
E
G
Name Explanation
A Submenu name This displays the submenu name.
B Operations/Settings
screen name
This displays the operations/settings screen name.
C Date and time The current date and time is displayed.
D “Home” icon Touch this to display the Top menu (P.18).
E Scroll buttons
Touch
on the right side of the screen to scroll to the right. Touch to scroll to the left. (The display changes according to the
direction you can scroll.)
F “Back” icon Touch this to go back to the previous menu.
G “Warning” icon The “Alarm list” screen is displayed when you touch this. (→ “Checking on current alarms” (P.35))
z In this document and on the unit, indoor units are described as the “I/D”.
z In this document and on the unit, outdoor units are described as the “O/D”.
Notations in this document
Menu names, screen names, etc., are shown as follows in this document.
Type Notation Example
Top menus
Screen names
Screen display items
“xxx” “Oper./Status”
“I/D unit list” screen
“Select” column, “ON/OFF”
Submenu names
Screen menu names
Button names
[xxx] [Operation/Status]
[I/D unit list]
[Operation]
