Panasonic Lumix S1H User Manual

5. Focus/Zoom
110
[225-Area]
The camera selects the most optimal AF
area to focus from 225 areas.
When multiple AF areas are selected, all
selected AF areas will be brought into
focus.
When the focus mode is set to [AFC],
ensuring that the subject stays within the
225 areas during recording will ensure the subject stays in focus.

Specify the [AFC] Start Point
When the focus mode is set to [AFC], you can specify at which area to start
[AFC].
1
Set the focus mode to [AFC]. (l 96)
2
Set [AFC Start Point (225-Area)] to [ON].
0
¨ [ ] ¨ [ ] ¨ [AFC Start Point (225-Area)] ¨ [ON]
3
Press [ ] to display the AF mode selection screen.
4
Select [ ] and then press 4.
0
After performing Steps 1 and 2, the icon changes from [ ] to [ ].
5
Press 3421 to move the AF area to the start point.
0
Positions can be moved to the diagonal directions using the joystick.
0 You can also move the AF area by touching.
0 To return the position back to the centre, press [DISP.].
6
Press .

Panasonic Lumix S1H Specifications

General

Sensor Type	Full-frame CMOS
Resolution	24.2MP
ISO Range	100-51200 (expandable to 50-204800)
Viewfinder	5.76 million-dot OLED
Sensor Size	35.6 x 23.8 mm
Lens Mount	L-Mount
Video Recording	6K/24p, 5.9K/30p, 4K/60p
Image Stabilization	5-axis in-body image stabilization
LCD Screen	3.2-inch, 2.33 million-dot touchscreen
Autofocus System	Contrast-detect DFD AF, 225-area
Connectivity	Wi-Fi, Bluetooth
Battery Life	Approx. 400 shots (CIPA standard)
Continuous Shooting	9 fps
Internal Recording	10-bit 4:2:2
Shutter Speed	1/8000 to 60 sec
Video Frame Rates	24p, 30p, 60p
Storage Media	Dual SD card slots (UHS-II compatible)
Weather Sealing	Yes
