Panasonic Lumix S1H

12. Connections with External Devices (Video)
330
Attaching the Cable Holder
Use of the supplied cable holder prevents detachment of the cable and
damage to the terminals.
0
Put the camera on a stable surface to perform this task.
1
While pushing A, slide the clamp
portion B of the cable holder to
remove it.
2
Open the door of the terminal section
and slide the door into the part marked
C.
3
Loosely mount the cable holder to the
mount on the camera, and then rotate
the screws in the direction of the
arrows to secure the cable holder. D
0 Use a “High Speed HDMI cable” with the HDMI logo.
Cables that do not comply with the HDMI standards will not work.
“High Speed HDMI cable” (Type A–Type A plug, up to 1.5 m (4.9 feet) long)
