Panasonic Lumix S1H User Manual

10. Recording Videos
286
This section describes the main assist functions that are convenient when
recording.
[SS/Gain Operation]
You can switch the units of shutter speed values and gain (sensitivity)
values.
¨ [ ] ¨ [ ] ¨ Select [SS/Gain Operation]
Main Assist Functions
0 The [Custom] ([Monitor / Display (Video)]) menu has display assist functions
such as the centre marker.
For details, refer to page 439.
[SEC/ISO] Displays the shutter speed in seconds and the gain in ISO.
[ANGLE/ISO]
Displays the shutter speed in degrees and the gain in ISO.
0 The angle can be set in a range between 11° and 358°.
(when [Synchro Scan] is set to [OFF])
[SEC/dB]
Displays the shutter speed in seconds and the gain in dB.
0 0 dB corresponds to either of the following ISO sensitivity
values.
– When [Dual Native Gain Setting] is set to [AUTO] or [LOW]:
[100]
– When [Dual Native Gain Setting] is set to [HIGH]: [640]

Panasonic Lumix S1H Specifications

General

Sensor Type	Full-frame CMOS
Resolution	24.2MP
ISO Range	100-51200 (expandable to 50-204800)
Viewfinder	5.76 million-dot OLED
Sensor Size	35.6 x 23.8 mm
Lens Mount	L-Mount
Video Recording	6K/24p, 5.9K/30p, 4K/60p
Image Stabilization	5-axis in-body image stabilization
LCD Screen	3.2-inch, 2.33 million-dot touchscreen
Autofocus System	Contrast-detect DFD AF, 225-area
Connectivity	Wi-Fi, Bluetooth
Battery Life	Approx. 400 shots (CIPA standard)
Continuous Shooting	9 fps
Internal Recording	10-bit 4:2:2
Shutter Speed	1/8000 to 60 sec
Video Frame Rates	24p, 30p, 60p
Storage Media	Dual SD card slots (UHS-II compatible)
Weather Sealing	Yes
