Panasonic Lumix S1H User Manual

15. Menu Guide
439
[Custom] menu ¨ [Monitor / Display (Photo)]
[Luminance Spot
Meter]
[ON]/`[OFF]
Specify any spot on the subject to measure the luminance
over a small area.
0 For details, refer to page 292.
[Framing Outline]
[ON]/`[OFF]
Displays the outline for the live view.
[Show/Hide Monitor
Layout]
[Control Panel] `[ON]/[OFF]
[Black Screen] `[ON]/[OFF]
Displays the control panel and black screen when switching
between displays using [DISP.] button. (l 70)
[Custom] menu ¨ [Monitor / Display (Video)]
[V-Log View Assist]
[Read LUT File]
[LUT Select]
[LUT View Assist
(Monitor)]
[ON]/`[OFF]
[LUT View Assist
(HDMI)]
[ON]/`[OFF]
You can show images with LUT data applied on the monitor/
viewfinder, or output them via HDMI.
0 For details, refer to page 310.
[HLG View Assist]
[Monitor] [MODE1]/`[MODE2]/[OFF]
[HDMI] `[AUTO]/[MODE1]/[MODE2]/[OFF]
At recording or playback of [HLG Photo] and HLG video, this
displays images with converted colour gamut and brightness
on the camera monitor/viewfinder, or outputs these over
HDMI.
0 For details, refer to page 314.

Panasonic Lumix S1H Specifications

General

Sensor Type	Full-frame CMOS
Resolution	24.2MP
ISO Range	100-51200 (expandable to 50-204800)
Viewfinder	5.76 million-dot OLED
Sensor Size	35.6 x 23.8 mm
Lens Mount	L-Mount
Video Recording	6K/24p, 5.9K/30p, 4K/60p
Image Stabilization	5-axis in-body image stabilization
LCD Screen	3.2-inch, 2.33 million-dot touchscreen
Autofocus System	Contrast-detect DFD AF, 225-area
Connectivity	Wi-Fi, Bluetooth
Battery Life	Approx. 400 shots (CIPA standard)
Continuous Shooting	9 fps
Internal Recording	10-bit 4:2:2
Shutter Speed	1/8000 to 60 sec
Video Frame Rates	24p, 30p, 60p
Storage Media	Dual SD card slots (UHS-II compatible)
Weather Sealing	Yes
