Panasonic Lumix S1H User Manual

15. Menu Guide
401
[Photo] menu ¨ [Image Quality]
[Filter Settings]
[Filter Effect] [ON]/`[OFF]/[SET]
l 216
[Simultaneous
Record w/o Filter]
[ON]/`[OFF]
This mode records with additional image effects
(filters).
[Photo] menu ¨ [Focus]
[AF Custom
Setting(Photo)]
`[Set 1]/[Set 2]/[Set 3]/[Set 4]
l 101
Select features of AF operation when recording
using [AFC] that are appropriate for the subject
and scene.
[AF Assist Light]
`[ON]/[OFF]
—
When recording in low light conditions, the AF
assist light turns on when you press the shutter
button halfway, making it easier for the camera to
focus.
0 The effective range of the AF assist light is
different depending on the lens used.
– When the interchangeable lens (S-R24105) is
attached and at wide-angle end.
Approx. 1.0 m (3.3 feet) to 3.0 m (9.8 feet)
0 Remove the lens hood.
0 The AF assist light may be greatly blocked, and
it may become harder to focus when a lens with
large diameter is used.
0 When [Silent Mode] is being used, [AF Assist
Light] is fixed to [OFF].

Panasonic Lumix S1H Specifications

General

Sensor Type	Full-frame CMOS
Resolution	24.2MP
ISO Range	100-51200 (expandable to 50-204800)
Viewfinder	5.76 million-dot OLED
Sensor Size	35.6 x 23.8 mm
Lens Mount	L-Mount
Video Recording	6K/24p, 5.9K/30p, 4K/60p
Image Stabilization	5-axis in-body image stabilization
LCD Screen	3.2-inch, 2.33 million-dot touchscreen
Autofocus System	Contrast-detect DFD AF, 225-area
Connectivity	Wi-Fi, Bluetooth
Battery Life	Approx. 400 shots (CIPA standard)
Continuous Shooting	9 fps
Internal Recording	10-bit 4:2:2
Shutter Speed	1/8000 to 60 sec
Video Frame Rates	24p, 30p, 60p
Storage Media	Dual SD card slots (UHS-II compatible)
Weather Sealing	Yes
