Panasonic Lumix S1H User Manual

5. Focus/Zoom
122

Setting Items ([Touch Pad AF])
[Focus Switching for Vert / Hor]
Memorises separate positions for AF areas
for when the camera is vertically aligned and
for when it is horizontally aligned.
Two vertical orientations, left and right, are
available.
¨ [ ] ¨ [ ] ¨ Select [Focus Switching for Vert / Hor]
[EXACT]
Moves the AF area of
the viewfinder by
touching a desired
position on the touch
pad.
[OFFSET1]
to
[OFFSET7]
Moves the AF area of
the viewfinder
according to the
distance you drag
your finger on the
touch pad.
Select the range to be detected with the drag operation.
[OFFSET1] (entire area)/[OFFSET2] (right half)/[OFFSET3] (upper
right)/[OFFSET4] (lower right)/[OFFSET5] (left half)/[OFFSET6]
(upper left)/[OFFSET7] (lower left)
[OFF] —
[ON] Memorises separate positions for vertical and horizontal orientations.
[OFF] Sets the same position for vertical and horizontal orientations.
0 In MF, this memorises the MF Assist position.
0 This does not work in the [ ] and [ ] to [ ] AF modes.
ヤヒ
ヤピ

Panasonic Lumix S1H Specifications

General

Sensor Type	Full-frame CMOS
Resolution	24.2MP
ISO Range	100-51200 (expandable to 50-204800)
Viewfinder	5.76 million-dot OLED
Sensor Size	35.6 x 23.8 mm
Lens Mount	L-Mount
Video Recording	6K/24p, 5.9K/30p, 4K/60p
Image Stabilization	5-axis in-body image stabilization
LCD Screen	3.2-inch, 2.33 million-dot touchscreen
Autofocus System	Contrast-detect DFD AF, 225-area
Connectivity	Wi-Fi, Bluetooth
Battery Life	Approx. 400 shots (CIPA standard)
Continuous Shooting	9 fps
Internal Recording	10-bit 4:2:2
Shutter Speed	1/8000 to 60 sec
Video Frame Rates	24p, 30p, 60p
Storage Media	Dual SD card slots (UHS-II compatible)
Weather Sealing	Yes
