Panasonic Lumix S1H User Manual

15. Menu Guide
414
[Video] menu ¨ [Audio]
[Sound Rec Gain
Level]
`[STANDARD]/[LOW]
l 284
This switches the gain of audio input.
[Sound Rec Level
Adj.]
[MUTE], [j18dB] to [i12dB] (`[0dB])
l 284
Manually adjust the sound recording level.
[Sound Rec Level
Limiter]
`[ON]/[OFF]
l 285
The sound recording level is adjusted
automatically to minimise sound distortion
(crackling noise).
[Wind Noise
Canceller]
[HIGH]/`[STANDARD]/[OFF]
l 285
This reduces the wind noise coming into the built-
in microphone while maintaining sound quality.
[Wind Cut]
[HIGH]/[STANDARD]/[LOW]/`[OFF]
l 342
This reduces wind noise when an external
microphone is connected.
[Mic Socket]
`[ ]/[ ]/[ ]
l 340
Sets the [MIC] socket input method that suits the
device to be connected.
[Special Mic.]
`[STEREO]/[LENS AUTO]/[SHOTGUN]/
[S.SHOTGUN]/[MANUAL]
l 341
Sets the sound pickup range when using the
Stereo Shotgun Microphone (DMW-MS2:
optional).
[XLR Mic Adaptor
Setting]
[96kHz/24bit]/[48kHz/24bit]/`[48kHz/16bit]/[OFF]
l 343
Sets the audio input for when an XLR Microphone
Adaptor (DMW-XLR1: optional) is attached.
[Sound Output]
`[REALTIME]/[REC SOUND]
l 345
Sets the audio output method when headphones
are connected.

Panasonic Lumix S1H Specifications

General

Sensor Type	Full-frame CMOS
Resolution	24.2MP
ISO Range	100-51200 (expandable to 50-204800)
Viewfinder	5.76 million-dot OLED
Sensor Size	35.6 x 23.8 mm
Lens Mount	L-Mount
Video Recording	6K/24p, 5.9K/30p, 4K/60p
Image Stabilization	5-axis in-body image stabilization
LCD Screen	3.2-inch, 2.33 million-dot touchscreen
Autofocus System	Contrast-detect DFD AF, 225-area
Connectivity	Wi-Fi, Bluetooth
Battery Life	Approx. 400 shots (CIPA standard)
Continuous Shooting	9 fps
Internal Recording	10-bit 4:2:2
Shutter Speed	1/8000 to 60 sec
Video Frame Rates	24p, 30p, 60p
Storage Media	Dual SD card slots (UHS-II compatible)
Weather Sealing	Yes
