Panasonic Lumix S1H User Manual

12. Connections with External Devices (Video)
342

Reduction of Wind Noise
This reduces wind noise when an external microphone is connected.
¨ [ ] ¨ [ ] ¨ Select [Wind Cut]
Settings: [HIGH]/[STANDARD]/[LOW]/[OFF]
0 You can register the [MANUAL] sound pickup range setting in an Fn button:
[] ¨ [ ] ¨ [Fn Button Set] ¨ [Setting in REC mode] ¨ [Mic. Directivity
Adjust] (l 367)
0 While the external microphone is connected, [ ] is displayed on the
screen.
0 When an external microphone is connected, [Sound Rec Level Disp.]
automatically turns [ON], and the recording level is displayed on the screen.
0 When [Mute Sound Input] is set to [ON], the audio input from the external
microphone is muted.
0 When the external microphone is attached, do not carry the camera by holding
the external microphone. It may become detached.
0 If noises are recorded when using the AC adaptor, use the battery.
0 When a Stereo Microphone (VW-VMS10: optional) is used, [Special Mic.] is
fixed to [STEREO].
0 Setting [Wind Cut] may alter the usual sound quality.
0 For details, refer to the operating instructions for the external microphone.

Panasonic Lumix S1H Specifications

General

Sensor Type	Full-frame CMOS
Resolution	24.2MP
ISO Range	100-51200 (expandable to 50-204800)
Viewfinder	5.76 million-dot OLED
Sensor Size	35.6 x 23.8 mm
Lens Mount	L-Mount
Video Recording	6K/24p, 5.9K/30p, 4K/60p
Image Stabilization	5-axis in-body image stabilization
LCD Screen	3.2-inch, 2.33 million-dot touchscreen
Autofocus System	Contrast-detect DFD AF, 225-area
Connectivity	Wi-Fi, Bluetooth
Battery Life	Approx. 400 shots (CIPA standard)
Continuous Shooting	9 fps
Internal Recording	10-bit 4:2:2
Shutter Speed	1/8000 to 60 sec
Video Frame Rates	24p, 30p, 60p
Storage Media	Dual SD card slots (UHS-II compatible)
Weather Sealing	Yes
