Panasonic Lumix S1H User Manual

10. Recording Videos
270
Synchronise the time code default value with an external device that
supports time code signal input and output.
A Flash synchro socket
B BNC conversion cable (for TC IN/OUT) (supplied)
C BNC cable (commercially available)
D External devices

Preparations for Time Code Synchronisation
When [Count Up] is set to [FREE RUN] in the [ ] mode, you can
synchronise the initial value of the time code with an external device.
1
Set the mode dial to [ ].
2
Set [Count Up] to [FREE RUN].
0
¨ [ ] ¨ [ ] ¨ [Time Code] ¨ [Count Up] ¨ [FREE RUN]
3
Rotate the flash synchro socket cap in the
direction of the arrow to remove.
0
Be careful not to lose the flash synchro socket
cap.
Synchronising the Time Code with an
External Device

Panasonic Lumix S1H Specifications

General

Sensor Type	Full-frame CMOS
Resolution	24.2MP
ISO Range	100-51200 (expandable to 50-204800)
Viewfinder	5.76 million-dot OLED
Sensor Size	35.6 x 23.8 mm
Lens Mount	L-Mount
Video Recording	6K/24p, 5.9K/30p, 4K/60p
Image Stabilization	5-axis in-body image stabilization
LCD Screen	3.2-inch, 2.33 million-dot touchscreen
Autofocus System	Contrast-detect DFD AF, 225-area
Connectivity	Wi-Fi, Bluetooth
Battery Life	Approx. 400 shots (CIPA standard)
Continuous Shooting	9 fps
Internal Recording	10-bit 4:2:2
Shutter Speed	1/8000 to 60 sec
Video Frame Rates	24p, 30p, 60p
Storage Media	Dual SD card slots (UHS-II compatible)
Weather Sealing	Yes
