Panasonic Lumix S1H User Manual

228
9. Flash
If you attach the Flash (DMW-FL580L/DMW-FL360L/DMW-FL200L:
optional) to the hot shoe, you can record using the flash.
You can also use a commercially available external flash by connecting a
synchro cable to the flash synchro socket.
Furthermore, by attaching an external flash that supports wireless flash
recording, you can wirelessly control an external flash that is in a position
separate from the camera.
Removing the Hot Shoe Cover
Before attaching the Flash (optional), remove the hot shoe cover.
Refer to the operating instructions for the Flash for details about how to
attach it.
Remove the hot shoe cover by
pulling it in the direction indicated
by arrow 2 while pressing it in the
direction indicated by arrow 1.
Using an External Flash (Optional)
0 Remove the lens hood to prevent vignetting.
0 Flash recording is not possible when the following functions are being used:
– [6K/4K PHOTO]/[Post-Focus]
– [ELEC.]/[Silent Mode]/[High Resolution Mode]
– [Filter Settings]



Panasonic Lumix S1H Specifications

General

Sensor Type	Full-frame CMOS
Resolution	24.2MP
ISO Range	100-51200 (expandable to 50-204800)
Viewfinder	5.76 million-dot OLED
Sensor Size	35.6 x 23.8 mm
Lens Mount	L-Mount
Video Recording	6K/24p, 5.9K/30p, 4K/60p
Image Stabilization	5-axis in-body image stabilization
LCD Screen	3.2-inch, 2.33 million-dot touchscreen
Autofocus System	Contrast-detect DFD AF, 225-area
Connectivity	Wi-Fi, Bluetooth
Battery Life	Approx. 400 shots (CIPA standard)
Continuous Shooting	9 fps
Internal Recording	10-bit 4:2:2
Shutter Speed	1/8000 to 60 sec
Video Frame Rates	24p, 30p, 60p
Storage Media	Dual SD card slots (UHS-II compatible)
Weather Sealing	Yes
