Panasonic Lumix S1H User Manual

12. Connections with External Devices (Video)
343
By attaching an XLR Microphone Adaptor (DMW-XLR1: optional) to the
camera, you can use a commercially available XLR microphone to enable
the recording of superior-quality high-res/stereo audio.
A Hot shoe
B Commercially available XLR microphone
Getting started:
0 Turn off the camera, and remove the hot shoe cover. (l 228)
1
Attach the XLR Microphone Adaptor to the hot shoe.
2
Set the camera on/off switch to [ON].
3
Select [XLR Mic Adaptor Setting].
≥ ¨ [ ] ¨ [ ] ¨ [XLR Mic Adaptor Setting]
XLR Microphone Adaptor (Optional)
[96kHz/24bit]
Records high resolution
audio at 96 kHz/24-bit.
Only available when
[Rec. File Format] is set
to [MOV].
[48kHz/24bit]
Records high-quality audio at
48 kHz/24-bit.
[48kHz/16bit] Records standard-quality audio at 48 kHz/16-bit.
[OFF]
Records audio using the built-in microphone of the
camera.

Panasonic Lumix S1H Specifications

General

Sensor Type	Full-frame CMOS
Resolution	24.2MP
ISO Range	100-51200 (expandable to 50-204800)
Viewfinder	5.76 million-dot OLED
Sensor Size	35.6 x 23.8 mm
Lens Mount	L-Mount
Video Recording	6K/24p, 5.9K/30p, 4K/60p
Image Stabilization	5-axis in-body image stabilization
LCD Screen	3.2-inch, 2.33 million-dot touchscreen
Autofocus System	Contrast-detect DFD AF, 225-area
Connectivity	Wi-Fi, Bluetooth
Battery Life	Approx. 400 shots (CIPA standard)
Continuous Shooting	9 fps
Internal Recording	10-bit 4:2:2
Shutter Speed	1/8000 to 60 sec
Video Frame Rates	24p, 30p, 60p
Storage Media	Dual SD card slots (UHS-II compatible)
Weather Sealing	Yes
