Panasonic Lumix S1H User Manual

10. Recording Videos
273
Synchronise the Time Code of the Camera with That
of the External Device (TC IN)
The initial time code value of the camera is synchronised according to the
time code signal (LTC signal) of the external device.
1
Prepare for time code synchronising. (l 270)
2
Set [TC Synchronization] to
[TC IN].
≥ ¨ [ ] ¨ [ ] ¨ [Time Code]
¨ [External TC Setting] ¨ [TC
Synchronization]
¨ [TC IN]
3
Operate the external device to
output the time code signal.
≥Set the time code count method of the external device to free run,
and output the signal.
≥When synchronised with the time code of an external device, this
camera is in a slave state, and the [ ] of the time code shown
on the screen switches to [ ].
0 In advance, change the [System Frequency] (l 253), [Rec Quality] (l 255),
and [Time Code Mode] (l 269) to match the external device.
0 When multiple units of this camera
are synchronised, the time code and
exposure timings are synchronised
so you can match the timings for
starting exposure between cameras.
0 The exposure timing can only be
synchronised the first time after [TC
Synchronization] is set to [TC IN].

Panasonic Lumix S1H Specifications

General

Sensor Type	Full-frame CMOS
Resolution	24.2MP
ISO Range	100-51200 (expandable to 50-204800)
Viewfinder	5.76 million-dot OLED
Sensor Size	35.6 x 23.8 mm
Lens Mount	L-Mount
Video Recording	6K/24p, 5.9K/30p, 4K/60p
Image Stabilization	5-axis in-body image stabilization
LCD Screen	3.2-inch, 2.33 million-dot touchscreen
Autofocus System	Contrast-detect DFD AF, 225-area
Connectivity	Wi-Fi, Bluetooth
Battery Life	Approx. 400 shots (CIPA standard)
Continuous Shooting	9 fps
Internal Recording	10-bit 4:2:2
Shutter Speed	1/8000 to 60 sec
Video Frame Rates	24p, 30p, 60p
Storage Media	Dual SD card slots (UHS-II compatible)
Weather Sealing	Yes
