5. Focus/Zoom
112

Move and Change the Size of the AF Area
1
Press [ ] to display the AF mode selection screen.
2
Select [ ], [ ] or [ ] and then press 4.
3
Press 3421 to move the position of
the AF area.
0
You can also move the AF area by
touching.
≥When [ ] is selected
– Press 34 to switch to a horizontal
pattern AF area.
– Press 21 to switch to a vertical pattern AF area.
≥When [ ]/[ ] are selected
– Positions can be moved to the diagonal directions using the joystick.
4
Rotate or to change the size of the AF area.
0
You can also pinch out/pinch in the AF area to change the size.
0 The first press of [DISP.] returns the AF area position to the centre. The second
press returns the size of the AF area to the default.
5
Press .
0 The display method for the AF area using 225-area focusing can be changed:
[] ¨ [ ] ¨ [AF Area Display] (l 433)

Panasonic Lumix S1H Specifications

General

Sensor Type	Full-frame CMOS
Resolution	24.2MP
ISO Range	100-51200 (expandable to 50-204800)
Viewfinder	5.76 million-dot OLED
Sensor Size	35.6 x 23.8 mm
Lens Mount	L-Mount
Video Recording	6K/24p, 5.9K/30p, 4K/60p
Image Stabilization	5-axis in-body image stabilization
LCD Screen	3.2-inch, 2.33 million-dot touchscreen
Autofocus System	Contrast-detect DFD AF, 225-area
Connectivity	Wi-Fi, Bluetooth
Battery Life	Approx. 400 shots (CIPA standard)
Continuous Shooting	9 fps
Internal Recording	10-bit 4:2:2
Shutter Speed	1/8000 to 60 sec
Video Frame Rates	24p, 30p, 60p
Storage Media	Dual SD card slots (UHS-II compatible)
Weather Sealing	Yes
