Panasonic Lumix S1H User Manual

5. Focus/Zoom
115

Move the Position of the AF Area
1
Press [ ] to display the AF mode selection screen.
2
Select [ ] and then press 4.
3
Press 3421 to set the position of [i] and then press or .
0
Positions can be moved to the diagonal directions using the joystick.
0 The selected position on the screen will be enlarged.
0 The AF area cannot be moved to the edge of the screen.
4
Press 3421 to fine-adjust the
position of [i].
5
Press or .
Operations on the Magnification Window
Button
operation
Touch
operation
Description of operation
3421 Touch
Moves [i].
0 Positions can be moved to the diagonal
directions using the joystick.
Pinch out/
pinch in
Enlarges/reduces the screen in small steps.
s Enlarges/reduces the screen.
Switches magnification window (windowed
mode/full screen mode).
[DISP.] [Reset]
First time: Returns to the screen in Step
3
.
Second time: Returns the AF area position to
the centre.

Panasonic Lumix S1H Specifications

General

Sensor Type	Full-frame CMOS
Resolution	24.2MP
ISO Range	100-51200 (expandable to 50-204800)
Viewfinder	5.76 million-dot OLED
Sensor Size	35.6 x 23.8 mm
Lens Mount	L-Mount
Video Recording	6K/24p, 5.9K/30p, 4K/60p
Image Stabilization	5-axis in-body image stabilization
LCD Screen	3.2-inch, 2.33 million-dot touchscreen
Autofocus System	Contrast-detect DFD AF, 225-area
Connectivity	Wi-Fi, Bluetooth
Battery Life	Approx. 400 shots (CIPA standard)
Continuous Shooting	9 fps
Internal Recording	10-bit 4:2:2
Shutter Speed	1/8000 to 60 sec
Video Frame Rates	24p, 30p, 60p
Storage Media	Dual SD card slots (UHS-II compatible)
Weather Sealing	Yes
