Panasonic Lumix S1H User Manual

7. Metering/Exposure/ISO Sensitivity
189
2
Set the aperture value.
≥Rotate or .
3
Start recording.
0 If the correct exposure is not achieved
when the shutter button is pressed
halfway, the aperture value and the
shutter speed blink red.

Depth of Field Characteristics
Aperture value Small Large
Focal length of lens Telephoto Wide-angle
Distance to subject Near More distant
Depth of field
(area in sharp focus)
Shallow (narrow)
Example: When you
want to take a image
with a defocused
background.
Deep (wide)
Example: When you
want to take a image
with focus as far as the
background.
F8.0F8.0F8.0

Panasonic Lumix S1H Specifications

General

Sensor Type	Full-frame CMOS
Resolution	24.2MP
ISO Range	100-51200 (expandable to 50-204800)
Viewfinder	5.76 million-dot OLED
Sensor Size	35.6 x 23.8 mm
Lens Mount	L-Mount
Video Recording	6K/24p, 5.9K/30p, 4K/60p
Image Stabilization	5-axis in-body image stabilization
LCD Screen	3.2-inch, 2.33 million-dot touchscreen
Autofocus System	Contrast-detect DFD AF, 225-area
Connectivity	Wi-Fi, Bluetooth
Battery Life	Approx. 400 shots (CIPA standard)
Continuous Shooting	9 fps
Internal Recording	10-bit 4:2:2
Shutter Speed	1/8000 to 60 sec
Video Frame Rates	24p, 30p, 60p
Storage Media	Dual SD card slots (UHS-II compatible)
Weather Sealing	Yes
