Panasonic Lumix S1H User Manual

15. Menu Guide
435
[Custom] menu ¨ [Monitor / Display (Photo)]
[Night Mode]
[Monitor] [ON]/`[OFF]
[LVF] [ON]/`[OFF]
Displays the monitor and viewfinder in red.
In dark environments, this reduces brightness of the screen
that can make the surroundings difficult to see.
You can also set the luminance of the red display.
1 Press 3421 to select [ON] on the monitor or
viewfinder (LVF).
2 Press [DISP.] to display the brightness adjustment
screen.
0 Display the monitor to adjust the monitor, and display
the viewfinder to adjust the viewfinder.
3 Press 21 to adjust luminance and then press or
.
0 This effect is not applied to images output via HDMI.
0 This menu item can be registered to the Fn button.
(l 367)
[LVF/Monitor Disp.
Set]
[LVF Disp. Set] []/`[]
[Monitor Disp. Set] []/`[]
Selects whether to show the live view without covering the
information display, or to display over the entire screen.
[]: Scales down images slightly so
you can better review the composition of
the images.
[]: Scales images to fill the entire
screen so you can see their details.
999
±
0
AFSAFS
L
FINE
999
±
0
L
AFSAFS
FINE
ISO
AUTO

Panasonic Lumix S1H Specifications

General

Sensor Type	Full-frame CMOS
Resolution	24.2MP
ISO Range	100-51200 (expandable to 50-204800)
Viewfinder	5.76 million-dot OLED
Sensor Size	35.6 x 23.8 mm
Lens Mount	L-Mount
Video Recording	6K/24p, 5.9K/30p, 4K/60p
Image Stabilization	5-axis in-body image stabilization
LCD Screen	3.2-inch, 2.33 million-dot touchscreen
Autofocus System	Contrast-detect DFD AF, 225-area
Connectivity	Wi-Fi, Bluetooth
Battery Life	Approx. 400 shots (CIPA standard)
Continuous Shooting	9 fps
Internal Recording	10-bit 4:2:2
Shutter Speed	1/8000 to 60 sec
Video Frame Rates	24p, 30p, 60p
Storage Media	Dual SD card slots (UHS-II compatible)
Weather Sealing	Yes
