Panasonic Lumix S1H User Manual

18. Materials
572
Removing dirt on the image sensor
The image sensor is very precise and delicate, so be sure to observe the
following when you do have to clean it yourself.
0
Blow dust off the surface of the image sensor using a commercially available blower.
Do not blow the dust off with excessive power.
0 Do not put the blower brush further inside than the lens mount.
0 Do not let the blower brush touch the image sensor as the image sensor may get
scratched.
0 Do not use any objects except a blower brush to clean the image sensor.
0 If you cannot remove the dirt or dust with the blower, consult the dealer or
Panasonic.

Cleaning the Viewfinder
If the viewfinder is dirty, then remove
the eye cup and clean.
While pushing the eye cup lock lever
A, rotate the eye cup in the direction
of the arrow and remove B.
Blow dirt off the surface of the
viewfinder using a commercially
available blower, then lightly wipe
with a soft, dry cloth.
0
After cleaning, align the fitting marks (#)
C and press and rotate the eye cup in
the direction of the arrow until a click is
heard
D.
0 Be careful not to lose the eye cup.






Panasonic Lumix S1H Specifications

General

Sensor Type	Full-frame CMOS
Resolution	24.2MP
ISO Range	100-51200 (expandable to 50-204800)
Viewfinder	5.76 million-dot OLED
Sensor Size	35.6 x 23.8 mm
Lens Mount	L-Mount
Video Recording	6K/24p, 5.9K/30p, 4K/60p
Image Stabilization	5-axis in-body image stabilization
LCD Screen	3.2-inch, 2.33 million-dot touchscreen
Autofocus System	Contrast-detect DFD AF, 225-area
Connectivity	Wi-Fi, Bluetooth
Battery Life	Approx. 400 shots (CIPA standard)
Continuous Shooting	9 fps
Internal Recording	10-bit 4:2:2
Shutter Speed	1/8000 to 60 sec
Video Frame Rates	24p, 30p, 60p
Storage Media	Dual SD card slots (UHS-II compatible)
Weather Sealing	Yes
