18. Materials
613
Flash (when using an external flash)
Flash mode Auto / Auto/Red-Eye / Forced Flash On / Forced On/Red-
Eye / Slow Sync. / Slow Sync./Red-Eye / Forced Flash Off
Flash
synchronisation
speed
Equal to or smaller than 1/320 of a second
¢
¢ The guide number decreases at 1/320 of a second,
only during [S]/[M] modes
Zoom
Extra Tele
Conversion
(Picture)
Max. 2k
¢
(when a picture size of [S] is selected.)
¢ Max. 1.9k when using Super 35 mm/APS-C lenses
Microphone / Speaker
Microphone Stereo
Speaker Monaural
Interface
USB USB Type-C™, SuperSpeed USB3.1 GEN1,
Supports USB Power Delivery (9.0 V/3.0 A)
0 Data from the PC cannot be written to the camera using
the USB connection cable.
[HDMI] HDMI Type A
[REMOTE] ‰ 2.5 mm jack
[MIC] ‰ 3.5 mm stereo mini jack,
Mic Input (Plug-in Power) / Mic Input / Line Input
(Operate the menu to switch between these inputs),
Standard input level: j55 dBV (Mic Input) / j10 dBV
(Line Input)
Headphones ‰ 3.5 mm stereo mini jack
Flash Synchro Ye s
TC IN/OUT Yes (connect the BNC conversion cable (supplied) to the
flash synchro socket)
Input: 1.0 V to 4.0 V [p-p], 10 kΩ
Output: 2.0 V d0.5 V [p-p], low impedance
Splash Resistant
Yes

Panasonic Lumix S1H Specifications

General

Sensor Type	Full-frame CMOS
Resolution	24.2MP
ISO Range	100-51200 (expandable to 50-204800)
Viewfinder	5.76 million-dot OLED
Sensor Size	35.6 x 23.8 mm
Lens Mount	L-Mount
Video Recording	6K/24p, 5.9K/30p, 4K/60p
Image Stabilization	5-axis in-body image stabilization
LCD Screen	3.2-inch, 2.33 million-dot touchscreen
Autofocus System	Contrast-detect DFD AF, 225-area
Connectivity	Wi-Fi, Bluetooth
Battery Life	Approx. 400 shots (CIPA standard)
Continuous Shooting	9 fps
Internal Recording	10-bit 4:2:2
Shutter Speed	1/8000 to 60 sec
Video Frame Rates	24p, 30p, 60p
Storage Media	Dual SD card slots (UHS-II compatible)
Weather Sealing	Yes
