Chapter 4 Settings — [PROJECTOR SETUP] menu
ENGLISH - 163
8) Press the <ENTER> button.
f [CALIBRATION TIME] is set.
Note
f The [REGULAR CALIBRATION] setting will be reected at the time when the item is switched using qw.
f The [CALIBRATION TIME] setting will be reected at the time when you enter the time and then press the <ENTER> button.
f The [REGULAR CALIBRATION] setting item is common with the following menu item.
g The [PROJECTOR SETUP] menu → [BRIGHTNESS CONTROL] → [BRIGHTNESS CONTROL SETUP] → [REGULAR CALIBRATION]
f The [CALIBRATION TIME] setting item is common with the following menu item.
g The [PROJECTOR SETUP] menu → [BRIGHTNESS CONTROL] → [BRIGHTNESS CONTROL SETUP] → [CALIBRATION TIME]
Setting [CALIBRATION MESSAGE]
Set whether to display the time to complete the measurement while the brightness and color of the light source
are measured.
1) Press as to select [BRIGHTNESS CONTROL].
2) Press the <ENTER> button.
f The [BRIGHTNESS CONTROL] screen is displayed.
3) Press as to select [CALIBRATION MESSAGE].
4) Press qw to switch the item.
f The items will switch each time you press the button.
[ON]
Displays the time to complete the measurement while the brightness and color of the light source are
measured by the brightness sensor.
[OFF]
Does not display a message during the measurement.
Note
f The [CALIBRATION MESSAGE] setting will be reected at the time when the item is switched using qw.
f The [CALIBRATION MESSAGE] setting item is common with the following menu item.
g The [PROJECTOR SETUP] menu → [BRIGHTNESS CONTROL] → [BRIGHTNESS CONTROL SETUP] → [CALIBRATION MESSAGE]
Brightness control adjustment procedure example
The steps exemplify an adjustment to link the brightness and white balance of eight projectors connected in a
network.
1) Connect all projectors to a switching hub using LAN cables. (x page 213)
2) Switch on all projectors and start projection.
3) Set [CONSTANT MODE] of [BRIGHTNESS CONTROL SETUP] to [OFF], and select [APPLY], and then
press the <ENTER> button.
4) Set [OPERATING MODE] of each projector to the same setting. (x page 155)
5) Set the administrator account, [SUBNET MASK], and [IP ADDRESS] of each projector.
f Set the administrator account (user name and password) of all linked projectors to the same setting.
f To be able to communicate over the network, set the same value in [SUBNET MASK] for all projectors and
set a dierent value in [IP ADDRESS] for each projector.
6) Wait for at least eight minutes after projection has started until the light source brightness becomes
steady.
7) Set all items in the [PICTURE] menu of all projectors to the same values.
8) Adjust [COLOR MATCHING] to match colors.
9) Display the internal test pattern “All white” in all projectors.
10) Set [LIGHT OUTPUT] of all projectors to 100 % or the maximum value that can be set.
f Depending on the [OPERATING MODE] settings, [LIGHT OUTPUT] may not be able to be set to 100 %.
11) Set [LIGHT OUTPUT] of the projector with the least brightness to 90 % or 10 % lower than the
maximum value that can be set.
To Next Page
